Designed to handle both cinematic and freestyle flying, Master 5 V2 with great Deadcat geometry, places the flight controller closer to the center of gravity than other DC frames

The innovative anti-vibration stack structure dampens the effect from motor noise on the gyro, offering a stabilized running environment.Averaging 1.5 screws per arm, the quick release structure makes assembly and disassembly easily

Honeycomb-shaped aluminum alloy CNC drone head ensures better strength and look, with H-FOV 130° section, drone head gets larger field of view.Furthermore, the incorporated DJI O3 Air Unit also supports ND filters and changeable side plate mounting.

SpeedyBee
KC1339
67,73 €
Impuestos incluidos RESERVA
Cantidad
Añadir a la lista de deseos
Añadir a comparar
FUERA DE STOCK

Chasis,  SpeedyBee
  Compra seguro. Usamos plataformas de pago seguras. Para garantías o reembolsos contáctanos.
  Envío rápido. 24/48 horas España. 3-7 días internacional.
  Política de devoluciones. Lea nuestros términos y condiciones.
Descripción
Frame Master 5 V2
Wheelbase 226mm
Weight About 140g (non-3D printed parts included)
Top plate thickness 2.5mm(T300 3K)
Middle plate thickness 2mm(T300 3K)
Bottom plate thickness 2.5mm(T300 3K)
Arm thickness 5mm(T300 3K)
Camera side plate thickness 2mm TUPC
Anti-vibration stack structure hardness Yellow HB80、Translucent HB50
3D printed par Yellow TPU
Motor circlip spacing φ8mm
Compatible propellers 5-5.1 inch
Mounting holes for motors 16*16mm
FC mounting hole 30.5×30.5(M3) & 20×20mm (M3)
Drone head 7075 CNC aluminum alloy
Aluminum standoff 7075 M3*23mm*(6mm/4.7mm)、M3*23mm*(4.6mm)
Internal installation height 23-30mm
Standard antenna installation suppor SMA (single), O3 4mm, RunCam Link
Standard GPS base size 18*18*8mm (other size requiresan additional purchase)
Rear Support Mounting Holes 20*20mm - 25.5*25.5mm - 30.5*30.5mm
Detachable stack protective plate RGB LED included
Motor wire protection included
Included 3D printed parts GOPRO base, capacitor/buzzerbase, arm protection, 181GPS base, T-antenna base, CNC drone head TPU protection, camera anti-vibration module
Buzzer TMB12A05
