Matek F405-WMN

Matek F405-WMN

49,50 €
Impuestos incluidos
 Reserva


Compra seguro. Usamos Paypal y otras plataformas de pago seguras.



Envío rápido. 24/48 horas España. 3-7 días internacional.



Política de devoluciones. Lea nuestros términos y condiciones.

Calcular Coste de Envío

Descripción

FC Specifications

MCU: STM32F405RGT6, 168MHz , 1MB Flash

IMU: ICM42688-P

Baro: SPL06-001

OSD: AT7456E

Blackbox: 16M Flash

5x UARTs,  1x Softserial_Tx option(INAV)

12x PWM outputs

1x I2C

3x ADC (VBAT, Current, RSSI)

1x spare PINIO

USB/Beep Extender with Type-C(USB2.0)

Built in inverter on UART2-RX for SBUS input

Switchable Dual Camera Inputs

Power

6~30V DC IN (2~6S LiPo)

132A Current Sense (INAV Scale 250, ArduPilot 40A/V)

PDB/Current sense resistor: 90A continuous, 132A burst.

BEC 5V 1.5A for FC & Peripherals

BEC Vx 5A for servos, 5V/ 6V option

Vbat for VTX and camera

LDO 3.3V 200mA

Battery Voltage Sensor: 1k:20k

FC Firmware

ArduPilot: MatekF405-TE

INAV: MATEKF405TE (INAV 5.0 or newer)
